Scott Voltage ERIDE 900 SL 2025 Electric Mountain Bike

Imagine giving the world’s best trail bike a secret weapon. With the Voltage eRIDE, that’s just what we did. Designed for existing MTB enthusiasts who crave an agile, lightweight and capable trail bike with the addition of a compact and quiet motor, the all-new Voltage eRIDE overdelivers trail after trail… after trail.

Frame

Carbon HMF

Integrated Suspension Technology

Virtual 4 Link kinematic / Adjustable head angle

Syncros Cable Integration System

TQ HPR50 / UDH Interface / 12x148mm with 55mm Chainline

Range Extender Ready

Travel

Front: 160mm / Rear: 155mm

Fork

FOX 36 Float Factory Air / Kashima FIT4

3 modes with low Speed adj. / Kabolt 15x110mm axle

44mm offset / tapered steerer / Reb. Adj. / Lockout

160mm travel

Rear Shock

FOX NUDE 6T Factory EVOL Trunnion

SCOTT custom w. travel / geo adj.

3 modes: Lockout-Traction Control-Descend

Low Speed Adj. / Custom large Air volume / Kashima / Reb. Adj.

Travel 155-100-Lockout / T185X55mm

Remote System

SCOTT TwinLoc 2 Technology

Suspension & Dropper Remote

3 Suspension modes

Drive Unit

TQ HPR50 Mid Motor drive 50Nm max Torque / EU: 25kmh / US: 20mph

Battery

TQ Internal 360Wh + Range Extender 160Wh (optional)

Display

TQ HPR

Bluetooth / ANT+ / Dedicated Smartphone app

Charger

TQ 100-240V-4A

Rear Derailleur

SRAM XX Eagle AXS Transmission 12 Speed

Wireless Electronic Shift System

Shifters

SRAM AXS Pod Ultimate Controller

Crankset

FSA Carbon crankset / 175mm / 34T

Chainguide

e*thirteen / e*spec Slider

Chainring

Scott custom spider / SRAM Eagle Transmission 34T chainring

Chain

SRAM CN XX Eagle Transmission

Cassette

SRAM XX Eagle XS 1297 Transmission 10-52

Brakes

SRAM Code Ultimate Stealth 4-Piston Disc

Rotor

SRAM HS2 Rotors F&R 200mm

Handlebar

Syncros Hixon iC Carbon

Size S & M 15mm rise / Size L & XL 25mm rise

back sweep 8° / 780mm

Syncros Endurance lock-on grips

Seatpost

Syncros Duncan Dropper Post 1.5S / Travel Adjust / 31.6mm

S size 140mm / M size 180mm / L & XL size 210mm

Seat

Syncros Tofino SL Regular 1.0

Carbon rails

Headset

Syncros – Acros Angle adjust & Cable Routing HS System

Stainless / +-0.6° head angle adjustment

ZS56/28.6 – ZS56/40 MTB

Wheelset

Syncros Revelstoke 1.0S-30 CL

F: 15x110mm

R: 12x148mm

30mm Tubeless ready Carbon rim 28H

DT Swiss 240 Ratchet EXP 36 / XD Driver

SRAM TyreWiz / Syncros Axle w/Removable Lever

with 6mm Allen

T30 and T25 Tools

Front Tire

Maxxis Dissector / 2.6″ / 60TPI Foldable

Tubeless Ready / EXO 3C maxx Terra

Rear Tire

Maxxis Dissector / 2.6″ / 60TPI Foldable

Tubeless Ready / EXO 3C maxx Terra

Extras

SRAM AXS Extension Cord

SRAM TyreWiz

Syncros Fork Fender

Approx weight in KG

17.9 (tubeless / without range extender)

Max. System Weight

128 kg

The overall weight includes the bike, the rider, the equipment, and possible additional luggage.

Please note that bike specifications are subject to change without prior notice.
