Passage 20 Wave is a full step-through E-Bike designed to take your urban riding to the next level. The open design makes it easy to mount and dismount the bike, whether on a commute or enjoying a tour around town.
The center of it all is the lightweight yet strong Bosch SX motor unit and tidy 400Wh battery. On the ride, the combo provides effortless performance on the pedals, accelerating smoothly over hills, delivering confident torque from a stop, and supplying the range to power you to your destination on the other side of town.
Handling is also light and easy, feeling more like a traditional bike than cumbersome and sluggish compared to a heavier urban E-Bike. The motor unit is just 2kg, low in the frame, and compact enough to provide confidence when navigating and a more natural pedaling style thanks to its favorable Q-factor.
We equipped this Passage 20 with a 75mm suspension fork to soften rough pavement on your routes and 45mm tires to add stability and durability no matter what comes your way. Its 9-speed drivetrain gives you the gearing range to ride around town like a pro, and the rear rack sets you up to stow the day’s essentials.
Key Features
- Passage eRIDE Alloy Frame
- Bosch SX, CT400 SmartSystem Engine System
- SR Suntour 75mm Fork
- Shimano Cues 9 Speed Drivetrain
- Shimano Disc Brakes
- Lezyne front light / Syncros integrated rear lights
- Racktime Micro rear rack, Snap it 2.0 compatible, 8Kg
Frame
Alloy S-L=29″, 6061 Alloy custom butted tubing
Top extraction battery
Travel
75mm
Fork
SR Suntour NRX32-E Air LO R, Tapered , 15×100 bolt Axle, Remote Lock Out , Steel Steerer, 75mm Travel
Drive Unit
Bosch Performance Line SX (BDU314Y)
EU: 25kmh
Battery
Compact Tube 400Wh
Display
Bosch Purion 200
Charger
2A Charger
Rear Derailleur
Shimano CUES RDU4000GS 9 Speed
Shifters
Shimano CUES SLU4009RC, 9 Speed
Crankset
FSA CK-220 170mm
Chainguide
Syncros
Chainring
FSA 38T
Chain
Shimano LG500
Cassette
Shimano LG300, 11-46T
Brakes
Shimano BR-MT200 Disc
Rotor
Front: SM-RT30 CL 180mm, Rear: SM-RT30 CL 160mm
Handlebar
Syncros Welded Alloy Combo 680mm, Backsweep 9°, Upsweep 8°, 70mm, with front Light mount
Seatpost
Syncros M3.0, 31.6
Seat
Syncros Capilano
Headset
Acros, 1.5″- 1.5″
semi integ. OD 50/61mm, ID 44/55mm
Hub (Front)
Shimano HBTC50015B CL, 15x100mm
Hub (Rear)
Shimano FHTC500HMB CL, 12x142mm
Spokes
Black Spokes
Rims
Syncros X15 Disc
Front Tire
Schwalbe G-One Overland 365 Performance, 700x45C
Rear Tire
Schwalbe G-One Overland 365 Performance, 700x45C
Lights
Lezyne Fusion E550SM front light
Rear Supernova TL3Z
Rack
Racktime Micro Rack SnapIt 2.0 8KG
Pedals
Marwi SP-827
Extras
Alumee alloy profile Fender
Passage Kickstand
Approx weight in KG
22.2
Max. System Weight
130kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
Please note that bike specifications are subject to change without prior notice.
